Feature precision glass etched reticles with multi-stage illumination in both red and green.
Mil Dot Illuminated Reticle
The classic Mil Dot features multiple aim points for hold-over and hold-under. Accurate mil spacing on 10x, featuring 4 Mil Dots in each direction. Glass etched reticle that has 5 brightness levels of illumination in both red and green, or can be turned off for a solid black reticle.
Specifications:
| Scope Tube | 1 Inch |
| Optical System | System H2 |
| Magnification | 3 - 9x |
| Objective Lens | 40mm |
| Reticle | Mil Dot IR |
| Illumination | 5 Levels (Red & Green) |
| Illumination Control | Stepped Rheostat |
| Parallax | Fixed |
| Focal Plane | SFP (Second Focal Plane) |
| Field of View | 39 - 12.7ft @100yds |
| Field of View (°) | 7.4 - 2.4 |
| Eye Relief | 3.5in |
| PX/Focus | 100yds |
| Exit Pupil | 0.52 - 0.17″ |
| Click Value | 1⁄ 4MOA |
| Elevation Turret Clicks (max) | 100 MOA |
| Windage Turret Clicks (max) | 100 MOA |
| Ocular Type | Fast Focus |
| Power Selector | Knurled Posi-Grip |
| Lens Coating | Fully Multi-Coated - 11 Layers |
| Length | 12.4in |
| Weight | 15.2oz |
| Turret Type (Elevation) | Capped. Low-Profile. Resettable |
| Turret Type (Windage) | Capped. Low-Profile. Resettable |
